Audco Slimseal and Aquaseal Wafer

Name: Audco Slimseal and Aquaseal Wafer
Brand: ARIHANT TRADING CO.

1000.00 - 7000.00 INR

Get a Price/Quote

Product Details:

Control System Manual Lever/Optional Gear Operated
Valve Size 50mm to 600mm
Connection Type Wafer Type
Material Cast Iron/ Ductile Iron body
Features Lightweight body, compact design, low torque, maintenance free, bidirectional, easy to install
Valve Type Wafer Type Butterfly Valve
Sealing Bubble Tight Shut Off
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Audco Slimseal and Aquaseal Wafer Price And Quantity

Price Range 1000.00 - 7000.00 INR
Minimum Order Quantity 50 Piece

Audco Slimseal and Aquaseal Wafer Product Specifications

Pin Yes
Valve Type Wafer Type Butterfly Valve
Pressure Medium Pressure
Disc EPDM/Ebonite Lined Disc (Optional Stainless Steel/DI/Aluminium Bronze/Polypropylene Disc)
Type Slimseal & Aquaseal Wafer Butterfly Valve
Application Water, Air, Gas, and Oil Industrial Applications
Temperature Up to 200C
Product Type Valve
Valve Size 50mm to 600mm
Control System Manual Lever/Optional Gear Operated
Port Size 50mm to 600mm
Media Water
Connection Type Wafer Type
Sealing Bubble Tight Shut Off
Material Cast Iron/ Ductile Iron body
Structure Wafer Type
Features Lightweight body, compact design, low torque, maintenance free, bidirectional, easy to install
Power Manual

Seating Material EPDM/Nitrile/Viton/Neoprene/PTFE Optional
Body Lining Epoxy coated for corrosion resistance
Gasket Integral seat design, eliminates the need for separate gaskets
Design Standard IS 13095 / EN 593
Shaft Material SS410/SS316
End Connection Wafer fit between flanges to BS10 Table D/E, ANSI 150, DIN PN 10/PN 16
Operation Lever or Gear Operated
Face to Face As per ISO 5752 / EN 558 Series 20
Handle Material Aluminum/SS
Mounting Top flange as per ISO 5211 for ease of automation

Audco Slimseal and Aquaseal Wafer Trade Information

Supply Ability 1000 Piece Per Week
Delivery Time 10-15 Days
Main Export Market(s) Western Europe, Australia, North America, Eastern Europe, Middle East, Central America, Africa, South America, Asia
Main Domestic Market All India

Product Description

Audco Slimseal and Aquaseal Wafer .

Slimseal and Aquaseal Valves

The elastomer liners of Slimseal and Aquaseal wafer-type butterfly valves are moulded directly on to the body and vulcanized in-situ. These integrally moulded liners last the entire life of the valve and require no maintenance.

Slimseal and Aquaseal are fit-and-forget valves, designed to outperform valves with loose liners.

Salient Features

* Longer life
* Bubble-tight sealing
* Low torque
* Assured sealing to atmosphere
* Easy installation

Type	Pressure rating	Units	Size Range
Slimseal	PN 16	Inches	2-24
Slimseal	PN 16	mm	50-600
Aquaseal	PN 10	Inches	2-12
Aquaseal	PN 10	mm	50-300

Materials of Construction
Slimseal - BS1452 Gr.250, BS2789 Gr.420/12, WCB, BS1400 AB2, CF8, CF8M, other materials available on demand.
Aquaseal - BS1452 Gr.200

Reliable Sealing and Maintenance-Free Operation

Audco Slimseal and Aquaseal Wafer Butterfly Valves employ an integral seat design, providing bubble-tight shut-off and eliminating the need for separate gaskets. Their robust construction and corrosion-resistant epoxy coating ensure long-term, maintenance-free performance, making them suitable for demanding industrial environments.

Versatile and Easy Installation

With a wafer fit design that matches multiple flange standards (BS10 Table D/E, ANSI 150, DIN PN 10/PN 16), installation is straightforward and secure. The body's lightweight, compact structure makes handling and mounting easy, while the top flange, as per ISO 5211, facilitates automation for flexible operational needs.

Tailored Performance for Diverse Applications

Available in a range of sizes and material options for discs and seats (EPDM, Nitrile, Viton, Neoprene, PTFE), these valves can be precisely specified for water, air, gas, or oil systems. Manual lever or optional gear operation allows users to select the control method best suited to their application's flow and pressure requirements.

FAQ's of Audco Slimseal and Aquaseal Wafer:

Q: How do I install the Audco Slimseal or Aquaseal Wafer Butterfly Valve?

A: These valves are designed for wafer-fit installation between standard flanges (BS10 Table D/E, ANSI 150, DIN PN 10/PN 16). Simply place the valve between the flanges and secure with bolts. The lightweight body and compact design make the installation process straightforward.

Q: What benefits does the integral seat design provide?

A: The integral seat design removes the need for separate gaskets, ensuring bubble-tight shut-off. This simplifies maintenance and minimizes the risk of leakage, enhancing valve efficiency and longevity.

Q: Where can these valves be used?

A: Audco Slimseal and Aquaseal Wafer Butterfly Valves are suitable for water, air, gas, and oil applications in various industrial settings. They support pressure up to medium levels and function reliably in systems with temperatures up to 200C.

Q: What options are available for disc and seating materials?

A: Disc options include EPDM, Ebonite, stainless steel, ductile iron, aluminum bronze, and polypropylene. Seating materials offered are EPDM, Nitrile, Viton, Neoprene, and PTFE, allowing customization based on media compatibility and operational requirements.

Q: How are these valves operated and can they be automated?

A: Standard operation is by manual lever, with gear operation available as an option for larger sizes. The ISO 5211 top flange accommodates easy actuator mounting, enabling automation when needed.

Q: What is the maintenance process for these wafer butterfly valves?

A: The valves are designed to be maintenance-free due to their robust construction and integral seat design. Regular system checks are advised, but the absence of separate gaskets and corrosion-resistant coating minimize required upkeep.

Q: What size range is available for these valves?

A: Audco Slimseal and Aquaseal Wafer Butterfly Valves are manufactured in sizes ranging from 50mm to 600mm, offering flexibility for various pipeline dimensions.
